Vertical Cable I-Punch Punch Down One-Step Termination Tool | V-Max CAT5e CAT6 CAT6A | 078-2150

The Vertical Cable I-Punch Tool (078-2150) is a professional-grade, one-step termination solution designed exclusively for V-Max Keystone Jacks. It seats and trims all eight conductors simultaneously in a single motion, completing terminations in as little as 18 seconds. The dual ratcheting mechanism delivers consistent pressure for reliable CAT5e, CAT6, and CAT6A connections, while the integrated cable cutter automatically trims excess wire for a flush finish. Built from heavy-duty low-carbon steel with a Black Oxide finish, this blade-free design eliminates ongoing maintenance costs. Features an integrated locking yoke for safe storage and comes with a lifetime warranty.

Features
One-Step Termination: Simultaneously seats and trims all conductors to save time and reduce hand fatigue.
Dual Ratcheting Mechanism: Applies even, stabilized pressure across all conductors for a reliable connection every time.
Integrated Cable Cutter: Trims excess wire automatically during the compression cycle, ensuring a flush finish.
Blade-Free Design: Eliminates the ongoing cost and maintenance of 110/66 blade replacements.
Integrated Locking Yoke: Features a built-in locking mechanism for safe, compact storage in your toolkit.
Heavy-Duty Construction: Built from low-carbon cold-rolled steel with a Black Oxide finish for long-term industrial durability.

Specifications
Compatibility: Exclusively for Vertical Cable V-Max CAT5e, CAT6, and CAT6A Keystone Jacks.
Construction Material: Heavy-duty low-carbon steel.
Blade Strength: Rated for 10,000+ cuts.
Mechanism Type: Mechanically stabilized ratcheting compression.
Compliance: TAA Compliant (Made in Taiwan).
Warranty: Lifetime Warranty.
Dimensions (L x W x H): 8.6” x 2.1” x 1.1”
Shipping Dimensions (L x W x H): 9.8” x 3.3” x 1.3”
Weight: 0.84 lbs (380g)
